OTT KANTOMAT

Universal edgebanding machines from Ott for crafts and interior design companies.

Initially, the machines were green. In the early 1990s, they were blue, but name and function remained the same. In 1996, the production was discontinued, but since 2007 new - now white - machines are built. New types have been introduced and the equipment has been changed. Series Strong Edge replaced in 2011 the series Kantomat.

Equipment

Basic equipment

Optional equipment

Models with free spaces can be upgraded with:

Technical data

  • Workpiece thickness up to 60 mm
  • Edge thickness
  • green/blue series: up to 15 mm
  • white series: up to 25 mm
  • Feed rate
  • green/blue series: 12 m/min and 18 m/min
  • white series: 10 m/min up to 16 m/min

Type designation

  • KM: Short for Kantomat
  • 1./2. digit: max. edge thickness in mm
  • 3.(/4.) digit: increasing numbers with increasing functionality of the machine
  • F: model with premilling unit
  • S: model with edge sanding aggregate

Images and Videos

Kantomat (Ott, grüne Baureihe)
OTT
OTT KANTOMAT KM F 2530
OTT, 2007
Video
OTT KANTOMAT KM F 2540
OTT, 2008
Video
KANTOMAT 156
OTT, 1995

Documents (3)

more
less

Type
