Technical data (Basic machine/ with additional device):

• Clamping device [mm]: 5.000 / 16.000
• Construction length [mm]: 10.000 / 50.000
• Speed bridge [m/min.]: 120 / 120
• Speed wagon [m/min.]: 120 / 120
• Speed hub drive [m/min.]: 60 / 60
• Workpiece length [mm]: 2.000 - 4.200 / max. 5.600
• Workpiece width [mm]: 800 - 2.200 / min. 400
• Workpiece raw panel [mm]: from 12 / from 3
• Workpiece weight [kg]: 250 / 350
• Stack height [mm]: 2.100 / 2.500
